JQ25 Assembly Wireless Connector Auto-locking

The JQ25 connector establishes new standards in industrial connectivity through its unique combination of wireless and physical connection technologies. The auto-locking system uses precision sensors and actuators to ensure perfect alignment and secure engagement, eliminating connection errors and reducing maintenance requirements. The hybrid approach provides redundant connectivity options, ensuring continuous operation even if one connection method experiences interference. Advanced encryption protocols (WPA3 and AES-256) secure all wireless communications, while the physical connection offe...

Inquiry

E-mail：sales01@szjiayunkang.com

WhatsApp：+86 13378428166

Detailed Description

Product Description
The JQ25 Assembly Wireless Connector with Auto-locking represents a breakthrough in industrial connectivity solutions, combining cutting-edge wireless technology with robust physical connection capabilities. Designed for the Industry 4.0 era, this innovative connector eliminates traditional wiring constraints while maintaining the reliability of physical connections. The auto-locking mechanism ensures secure mating without manual intervention, making it ideal for automated production environments and hard-to-reach applications. With IP65 protection rating and enhanced EMI shielding, the JQ25 maintains stable performance in challenging industrial environments while providing the flexibility of wireless data transmission.

Application:

The series are widely used in LED industry (street lights, display screens, lighting, landscape), communications, automation, new energy, marine electronics, medical equipment, security, positioning systems, automotive circuit systems, etc.

Smart Manufacturing: Automated production lines and robotic systems
Industrial IoT: Sensor networks and equipment monitoring
Mobile Equipment: AGVs and autonomous mobile robots
Modular Machinery: Quick-change production systems
Harsh Environments: Food processing, chemical, and pharmaceutical plants
Outdoor Applications: Weather-resistant wireless connectivity
Testing Equipment: Rapid connection/disconnection for test benches
Energy Sector: Wind turbine and solar installation monitoring

Features:

1. Quick auto-locking connection mode, easy docking, strong foolproof, blind plugging;

2. Multi-core product structure satisfies the diversified industrial requirements;

3. The GND is in contact first, and the live wire & zero wire are in contact later, which is safer and more reliable;

4. Using high-performance thermoplastic material, which has high temperature resistance, UV resistance, fire resistance, flame retardant, explosion-proof and oil resistance;

5. Adopt high-performance copper alloyed cores, gold plating, to guarantee electrical performance;

6. Protection level up to IP65/IP67;

7. Mainly used in LED display, high-current equipment, automation equipment and other fields, with multi-core combination to present product characteristics.

Performance Advantages

50% Faster Installation: Auto-locking eliminates manual connection time
Enhanced Reliability: Dual connectivity ensures uninterrupted operation
Reduced Maintenance: Self-cleaning contacts and corrosion-resistant materials
Future-Proof Design: Firmware upgradeable for new protocols
Energy Efficient: Low-power wireless technology with automatic sleep mode
Scalable Deployment: Supports mesh networking for large installations
Compliance Certified: Meets IEC 61076-2-101 and FCC Part 15 standards
Long Service Life: Rated for 10,000+ mating cycles

Parameters:

Cores layout:	2 pins	3 pins	4 pins	5 pins	6 pins	9 pins	3+5 pins	3+9 pins	3+13 pins	3+16 pins
Rated voltage:	250V	250V	250V	250V	250V	250V	250+50V	250+50V	250+50V	250+50V
Rated current:	30A	30A	20A	20A	15A	5A	20+5A	20+5A	20+5A	20+5A
OD of cores:	Φ2.4mm	Φ2.4mm	Φ2.4mm	Φ2.0mm	Φ2.0mm	Φ1.0mm	Φ2.4mm+Φ1.0mm	Φ2.4mm+Φ1.0mm	Φ2.4mm+Φ1.0mm	Φ2.4mm+Φ1.0mm
Workable wire:	≤ 4mm² (16~12AWG)	≤ 4mm² (16~12AWG)	≤ 2.5mm² (18~14AWG)	≤ 2.5mm² (18~14AWG)	≤ 1.5mm² (24~16AWG)	≤ 0.5mm² (26~20AWG)	≤ 2.5mm² (20~14AWG)	≤ 2.5mm² (20~14AWG)	≤ 2.5mm² (20~14AWG)	≤ 2.5mm² (20~14AWG)
Wire gauge:	OD ≤ 13.5mm
Protection level:	IP65/67
Connection mode:	Quick auto-locking
Operating temperatures:	-40℃ ~ +105℃
Shell & Insulation parts:	High-performance engineering plastics (PA or PVC)
Cores material:	Copper alloy

Frequently Asked Questions (FAQ)

Q1: How does the auto-locking mechanism work?
A: The connector uses infrared sensors to detect proper alignment, then activates precision actuators to engage the locking mechanism automatically, providing both visual and audible confirmation of secure connection.

Q2: What wireless protocols are supported?
A: The JQ25 supports Bluetooth 5.2 for short-range connections and WiFi 6 for high-speed data transfer, with seamless switching between protocols based on signal strength and bandwidth requirements.

Q3: Can it operate in electrically noisy environments?
A: Yes, the connector features enhanced EMI shielding and frequency hopping technology to maintain reliable wireless communication even in high-interference environments.

Q4: What is the range of wireless connectivity?
A: The wireless range is up to 50 meters indoors and 100 meters outdoors with line of sight, depending on environmental conditions.

Q5: How is power managed between wireless and physical connections?
A: The physical connection handles primary power delivery (up to 120W), while the wireless interface operates on low power with automatic energy-saving modes when not actively transmitting data.

Q6: Are custom configurations available?
A: Yes, we offer customization options including specific wireless protocols, housing materials, and connector orientations to meet unique application requirements.

Q7: What cybersecurity measures are implemented?
A: The connector features hardware-based security including secure boot, encrypted storage, and certificate-based authentication, meeting industrial cybersecurity standards.
