Product Description
The Assembly Auto-locking Connector JQ16 represents a breakthrough in industrial connectivity solutions, specifically engineered for secure and efficient device connections in demanding applications. This innovative connector series features an intelligent auto-locking mechanism that ensures perfect mating every time, eliminating connection errors and enhancing operational safety. Designed for high-vibration environments and rough handling conditions, the JQ16 maintains reliable performance while significantly reducing installation time. The connector's robust construction meets IP68 standards when properly mated, providing complete protection against dust, water, and chemical exposure. With its superior electrical properties and mechanical durability, the JQ16 sets new standards for reliability in industrial automation, medical equipment, and heavy machinery applications.

Advanced Technical Features

• Smart Auto-Locking System: Integrated mechanism provides audible and tactile confirmation of secure mating

• IP68 Environmental Protection: Maximum protection against dust, water immersion, and chemical splashes

• High-Vibration Resistance: Specialized design maintains connection integrity in extreme vibration conditions

• Multi-Pin Configuration: Available in 4-16 pin options with mixed signal/power contacts

• EMI/RFI Shielding: 360° shielding provides excellent electromagnetic compatibility

• High-Temperature Performance: Operates reliably in -40°C to +125°C environments

• Color-Coded Housing: Quick visual identification for different applications and voltages

• Tool-Free Assembly: Field-installable design requires no special tools for termination

Applications:

It is mainly used in LED, outdoor illumination, lighting, lamps, stage lighting, medical equipment and other fields.

• Industrial Robotics: Joint connections, sensor interfaces, and power transmission

• Medical Equipment: Patient monitoring systems, diagnostic equipment, and mobile medical devices

• Agricultural Machinery: GPS systems, sensor networks, and implement controls

• Transportation Systems: Railway signaling, vehicle control systems, and fleet monitoring

• Energy Sector: Renewable energy systems, grid monitoring equipment, and power distribution

• Factory Automation: PLC connections, motor controls, and sensor networks

• Marine Equipment: Navigation systems, communication devices, and onboard electronics

• Military Applications: Field equipment, communication systems, and vehicle electronics

Features:

1. Quick auto-locking connection mode, easy docking, strong foolproof, blind plugging;

2. Multi-core product structure satisfies the diversified industrial requirements;

3. The GND is in contact first, and the live wire & zero wire are in contact later, which is safer and more reliable;

4. Using high-performance thermoplastic material, which has high temperature resistance, UV resistance, fire resistance, flame retardant and oil resistance;

5. Adopt high-performance copper alloyed cores, gold plating, to guarantee electrical performance;

6. Protection level up to IP65/IP67;

7. Mainly used in LED, outdoor illumination, lighting, lamps, stage lighting, medical equipment and other fields.

Parameters:

Frequently Asked Questions (FAQ)

Q1: How does the auto-locking mechanism work?
A: The JQ16 features a precision-engineered mechanism that automatically engages when connectors are properly aligned. Users simply push the connectors together until they hear an audible click, indicating secure locking. To disconnect, press the release button and gently pull apart.

Q2: What makes the JQ16 suitable for medical applications?
A: Our connector meets medical-grade requirements with its high reliability, easy cleaning surface finish, and compatibility with sterilization processes. The auto-locking feature prevents accidental disconnections critical for patient safety.

Q3: Can the connector handle both power and signals?
A: Yes, the JQ16 offers mixed contact configurations that combine power contacts (up to 16A) with sensitive signal contacts (up to 5A) in the same housing, simplifying system design.

Q4: What cable types are compatible?
A: The connector accommodates various cable types including PUR, PVC, and silicone cables with diameters from 6mm to 12mm. Shielded and unshielded versions are available.

Q5: How does the IP68 rating benefit outdoor applications?
A: The IP68 rating ensures complete protection against dust ingress and continuous immersion in water, making it ideal for outdoor equipment, agricultural machinery, and marine applications.

Q6: Are custom configurations available?
A: Yes, we offer custom pin assignments, special colors, and unique keying options to prevent mismating in complex systems. Contact our engineering team for specific requirements.

Q7: What safety certifications does the connector hold?
A: The JQ16 meets UL, CSA, and CE requirements, with specific certifications available based on application needs and regional requirements.
