Product Description
The JQ12 Auto-locking Type Mini Waterproof Connector is a compact, high-performance interconnection solution designed for applications where space is limited but reliability cannot be compromised. As a specialized manufacturer of waterproof connectors, Shenzhen Jiayunkang Technology has engineered the JQ12 series to meet the growing demand for miniaturized yet robust connectivity in various industrial and commercial sectors.

Despite its small form factor, this connector delivers impressive performance with an IP67 protection rating, ensuring complete protection against dust infiltration and water immersion. The innovative auto-locking mechanism provides a secure connection that prevents accidental disconnection even in high-vibration environments. The connector features precision gold-plated contacts that ensure stable signal transmission and low contact resistance, making it suitable for both power and data applications. With its compact design and reliable performance, the JQ12 is an ideal solution for modern electronic devices requiring space-saving waterproof connectivity.

Features

1. Quick auto-locking connection mode, easy docking, strong foolproof, blind plugging;


2. Multi-core product structure satisfies the diversified industrial requirements;


3. The GND is in contact first, and the live wire & zero wire are in contact later, which is safer and more reliable;


4. Using high-performance thermoplastic material, which has high temperature resistance, UV resistance, fire resistance, flame retardant and oil resistance;


5. Adopt high-performance copper alloyed cores, gold plating, to guarantee electrical performance;


6. Protection level up to IP65/IP67;


7. Mainly used in LED display, stage lighting, audio electronics, automation equipment, plant lights, energy storage and other applications.


Product parameters

Product Features

• Compact Mini Design: Space-saving form factor ideal for compact electronic devices and equipment

• IP67 Waterproof Rating: Complete protection against dust and water immersion

• Auto-locking Mechanism: Secure connection that prevents accidental disconnection

• High-Density Configuration: Multiple contact options in a minimal footprint

• Gold-Plated Contacts: Excellent conductivity and corrosion resistance

• High Temperature Resistance: Operates reliably in extreme temperature conditions

• Vibration Resistant: Stable performance in high-vibration environments

• 360° EMI Shielding: Provides electromagnetic interference protection

• Color Coding Options: Available in multiple colors for easy identification and matching

• Quick Assembly: Designed for easy and efficient installation




Application Fields
The JQ12 Mini Waterproof Connector is versatile and suitable for numerous applications including:

• Portable medical devices and monitoring equipment

• Industrial sensors and automation systems

• UAVs and drone systems

• Automotive electronics and vehicle sensors

• Consumer electronics and wearable devices

• Telecommunications equipment

• Outdoor monitoring and security devices

• Robotics and mechatronic systems

• Marine and aquatic equipment

• Agricultural monitoring systems

Frequently Asked Questions (FAQ)

Q1: What is the IP rating of the JQ12 connector?
A: The JQ12 features an IP67 rating, providing complete protection against dust and water immersion up to 1 meter for 30 minutes.

Q2: How does the auto-locking mechanism work?
A: The auto-locking system uses a secure latch mechanism that engages automatically when the connectors are mated, providing audible and tactile confirmation of proper connection.

Q3: What is the maximum current rating for the JQ12 connector?
A: The current rating varies by contact configuration. Typical ratings range from 2A to 5A per contact, depending on the specific model and application requirements.

Q4: Can the JQ12 connector withstand harsh industrial environments?
A: Yes, the JQ12 is designed to perform reliably in challenging conditions, including exposure to vibration, temperature extremes, and moisture.

Q5: Are custom cable lengths available?
A: Yes, we offer complete customization options including cable length, wire gauge, and connector configuration to meet specific application requirements.

Q6: What materials are used in the JQ12 connector construction?
A: The connector uses high-quality engineering thermoplastics for the housing and gold-plated copper alloy for the contacts, ensuring durability and excellent electrical performance.

Q7: Is the connector compatible with automated assembly processes?
A: Yes, the JQ12 is designed for compatibility with automated pick-and-place and assembly equipment, facilitating high-volume production.

Details
