Product Description

Shenzhen Jiayunkang Technology Co., Ltd. specializes in high-performance connectivity solutions built to withstand the elements. Our M15 Outdoor Brass male and female connectors are engineered for applications where reliability is non-negotiable. Featuring a robust brass body with a precision-threaded M15 x 1.0 coupling mechanism, these connectors provide a secure, vibration-resistant seal that stands up to moisture, dust, and mechanical stress.

This connector series is designed for quick and easy field installation, allowing for the creation of reliable power and signal connections in outdoor and industrial settings. The male and female variants are built to mate perfectly, ensuring a consistent and stable electrical path. Ideal for completing wiring systems in LED lighting, industrial sensors, and small-scale machinery, these connectors are a testament to our commitment to quality and durability in every component we manufacture.

Product Features

Rugged Brass Construction: The core body is made from high-quality brass, offering excellent corrosion resistance, superior mechanical strength, and long-term durability in harsh conditions.

Precision M15 x 1.0 Threading: Ensures a fast, secure, and vibration-proof connection, preventing accidental loosening and maintaining seal integrity.

Integrated Sealing Ring: Each connector is equipped with a high-grade silicone or nitrile O-ring, providing an immediate and effective seal against water and dust ingress upon mating.

High-Temperature Resistant Insulation: The internal PBT or nylon insulator maintains its structural integrity and insulating properties even in elevated temperature environments.

Wide Cable Grip Range: The integrated rubber seal or compression gland accommodates a broad range of cable diameters, from 4mm to 8mm, ensuring a tight and strain-relieved fit.

Plated Contacts: The pin/socket contacts are often gold or nickel-plated to minimize contact resistance, prevent oxidation, and ensure optimal signal integrity and power transmission.

Product Advantages

Unmatched Environmental Protection: The combination of the metal body, threaded coupling, and integrated sealing offers a high degree of protection, typically rated at IP67 or higher, making these connectors impervious to rain, hose-directed water, and dusty conditions.

Extended Service Life in Corrosive Atmospheres: The brass body provides inherent resistance to corrosion, significantly outperforming standard Plastic connectors in outdoor, marine, or industrial environments where chemical exposure is a concern.

Enhanced EMI Shielding: The all-metal brass body acts as a natural shield against electromagnetic interference (EMI), protecting signal integrity in electrically noisy environments common in automation and power supply applications.

Streamlined Maintenance and Repairs: The plug-and-play design allows for quick disconnection and reconnection of devices, dramatically simplifying system troubleshooting, component replacement, and routine maintenance procedures.

Proven Vibration Resistance: The finely machined threads lock securely in place, making this connector series the ideal choice for applications on moving machinery, vehicles, and equipment subject to constant shock and vibration.

Application Fields

The durability and reliability of our M15 brass connectors make them indispensable across a wide spectrum of industries:

Outdoor & Industrial LED Lighting: Perfect for connecting LED street lights, floodlights, high-bay lights, and landscape lighting where waterproofing is critical.

Factory Automation: Used for sensors, actuators, and small motors on production lines and robotic arms that require a compact yet robust connection.

Agricultural and Construction Machinery: Provides dependable power and signal links on equipment exposed to mud, moisture, and extreme physical shocks.

Renewable Energy Systems: Ideal for interconnections in solar panel arrays and monitoring sensors in wind turbines.

Marine and Outdoor CCTV: Ensures continuous operation of security and navigation equipment in wet and corrosive salt-air environments.

Frequently Asked Questions (FAQ)

Q1: What is the IP rating of your M15 Brass connectors?
A: When properly mated, our standard M15 Brass Connectors achieve an IP67 rating, meaning they are dust-tight and can withstand temporary immersion in water up to 1 meter for 30 minutes.

Q2: Are these connectors suitable for high-vibration applications?
A: Yes, absolutely. The precision M15 x 1.0 threading creates a mechanically secure lock that is highly resistant to loosening under vibration, making them superior to push-pull or bayonet-style connectors in such conditions.

Q3: What is the temperature operating range?
A: The brass body and high-temperature insulator allow these connectors to perform reliably in a wide temperature range, typically from -25°C to +85°C, and up to +105°C for specific models.

Q4: Can I use these connectors for both power and signal transmission?
A: Yes. These connectors are versatile and can be configured for power (e.g., 2-4 pins) or signal (e.g., 3, 4, or 5 pins for sensors) transmission, making them a flexible solution for various wiring needs.
