Product Description

Shenzhen Jiayunkang Technology Co., Ltd. specializes in advanced connectivity solutions for demanding environments. Our M15 L-shaped LED waterproof connector is a specialized component engineered to provide a reliable and protected power link for LED lighting systems where space is limited and exposure to the elements is a concern. This connector features a compact, right-angle design that allows for efficient cable routing in confined areas, preventing awkward cable bends and reducing strain on the connection point.

With a robust M15x1.0 threaded coupling mechanism, it ensures a quick, secure, and vibration-proof connection. The integrated sealing rings provide a high degree of protection against moisture, dust, and other environmental contaminants. Primarily used for DC power transmission in LED applications, this connector is an essential accessory for achieving a professional, durable, and long-lasting lighting installation, simplifying both initial setup and future maintenance.

Product Features

Space-Saving L-Shape Design: The right-angle form factor enables installation in tight spaces and allows for cleaner cable management along walls or within luminaire housings.

M15 Threaded Coupling: Features a standard M15x1.0 thread for a fast, secure, and reliable screw-on connection that resists loosening under vibration.

High IP Protection Rating: Rated at IP67, making it dust-tight and capable of withstanding temporary immersion in water, ideal for outdoor and wet-location use.

Optimized for LED Systems: Typically configured with 2 or 3 pins, perfectly suited for low-voltage DC power input to LED modules, drivers, and fixtures.

Robust Material Construction: The housing is made from high-quality PBT plastic for excellent UV resistance, temperature stability, and mechanical strength, while the contacts are gold-plated for superior conductivity and corrosion resistance.

Easy Installation: Designed for tool-assisted assembly, allowing for quick wire termination and secure crimping or screwing of the contacts.

Product Advantages

Eliminates Cable Strain: The L-shaped design naturally directs the cable away from the port, significantly reducing mechanical stress on the solder points or terminals inside the LED fixture, which extends the product's lifespan.

Enhanced System Reliability: The combination of the secure threaded lock and IP67 sealing ensures an uninterrupted power supply, preventing failures caused by water ingress, dust contamination, or loose connections in critical outdoor and industrial LED applications like street lighting and architectural illumination.

Streamlined Aesthetics and Installation: This connector helps create a more professional and integrated look by enabling neater cable routing. It solves the common problem of bulky straight connectors requiring excessive clearance, thereby speeding up the installation process.

Durability in Harsh Conditions: The materials are selected to perform reliably in a wide temperature range and resist degradation from sunlight, salinity, and industrial atmospheres, making it a perfect choice for marine electronics, outdoor signage, and automation equipment.

Global Market Compatibility: Designed to meet international standards for Electrical Connectors, ensuring broad compatibility with LED drivers and fixtures used in markets worldwide.

Application Fields

The M15 L-shaped LED Waterproof Connector is indispensable in any application where reliable DC power connection and environmental protection are paramount.

Outdoor LED Lighting: The premier choice for LED street lights, floodlights, high-bay lights, garden lights, and landscape lighting systems.

LED Display Screens: Provides secure power and signal connections for outdoor and indoor LED video displays and digital signage.

Industrial Machinery & Automation: Used for connecting sensors, low-power actuators, and control panel indicators in environments with coolant, dust, or high vibration.

Architectural & Commercial Lighting: Ideal for concealed lighting installations, channel letters, and cabinet lighting where space is constrained and a clean finish is required.

Marine and Automotive Electronics: Suitable for providing waterproof power connections in non-submersion marine applications and commercial vehicle lighting.

Frequently Asked Questions (FAQ)

Q1: What is the difference between an M15 and an M12 Connector?
A: The primary difference is the size and threading. The M15 connector has a larger thread diameter (15mm) compared to the M12 (12mm). While both can be waterproof, the M15 is often favored in LED lighting for its slightly larger profile, which can handle higher current requirements common in power transmission for lights.

Q2: Is the L-shape available in both plug and socket versions?
A: Yes, we typically offer the M15 L-shaped connector in mating pairs, meaning you can get a cable-mounted plug and a panel-mounted socket, both in the L-shape design, to complete a fully protected connection system.

Q3: What is the maximum current and voltage rating for this connector?
A: Standard versions are commonly rated for up to 250V and 4-5A per pin, making them perfectly suited for a wide range of LED lighting applications. Please consult the specific product datasheet for detailed electrical ratings.

Q4: Can I get pre-assembled cables with these connectors?
A: Absolutely. We can provide custom-length, pre-wired cable assemblies with the M15 L-shaped connectors attached, ready for plug-and-play installation to reduce your labor costs and ensure consistency.
