Product Description

The M12 5-pin sensor connector is an industry-standard circular connector designed for robust and reliable signal transmission in industrial automation and sensor applications. As a leading manufacturer of Waterproof Connectors, Shenzhen Jiayunkang Technology Co., Ltd. has engineered this A-coded connector to meet the rigorous demands of modern manufacturing environments. It is precision-machined to ensure a secure connection, featuring a durable polyamide (PA66) housing and gold-plated brass contacts for superior signal integrity. The connector's threaded coupling mechanism provides a vibration-resistant lock, while its advanced sealing design guarantees an IP67 rating, making it completely dust-tight and protected against temporary immersion in water. This connector is the ideal solution for connecting a wide array of sensors, including photoelectric, proximity, and pressure sensors, to Programmable Logic Controllers (PLCs) and control systems.

Key Features

5-Pin A-Coding: Standardized for 3-wire DC sensors and devices, ensuring correct mating and preventing mismating with other M12 codings.

Robust IP67 Protection: Offers complete protection against dust and water ingress, capable of withstanding immersion in up to 1 meter of water for 30 minutes, ideal for wash-down environments and outdoor use.

High-Quality Materials: Features a PA66 housing for excellent chemical and impact resistance, with brass, gold-plated contacts for low resistance and stable electrical performance.

Secure Threaded Coupling: The reliable M12x1 thread ensures a vibration-proof connection that will not loosen under stress or in high-vibration machinery.

Excellent EMI Shielding: The metal shell variant provides effective electromagnetic interference shielding, protecting signal integrity in electrically noisy environments.

Wide Temperature Range: Operates reliably in temperatures from -25°C to +85°C, ensuring performance in both cold storage and high-temperature factory settings.

Flexible Cable Options: Available with PVC or PUR cable jackets; PUR offers superior resistance to oil, abrasion, and chemicals for harsher applications.

Competitive Advantages

Our M12 5-pin connectors provide distinct advantages that enhance system reliability and reduce total cost of ownership. Unlike generic alternatives, our connectors undergo a 100% continuity and hi-pot test before shipment, guaranteeing zero defects. The gold plating on the contacts is thicker than industry standard, significantly reducing oxidation and ensuring a stable connection over thousands of mating cycles, which minimizes downtime and maintenance costs. Furthermore, our integrated design combines the plug and cable into a single, molded unit, eliminating internal failure points common in field-assembled connectors and providing superior strain relief. This results in a product that not only meets but exceeds the performance and longevity expectations of our global clients in automation, automotive, and LED lighting sectors.

Application Fields

The versatility and durability of the M12 5-pin A-coded connector make it indispensable across numerous industries.

Factory Automation: Primarily used for connecting sensors (inductive, capacitive, photoelectric), limit switches, and I/O modules on automated production lines and robotic arms.

Packaging Machinery: Ensures reliable signal transmission in high-speed packaging and bottling plants, where moisture and frequent wash-downs are common.

Automotive Manufacturing: Used extensively in assembly line robotics, welding systems, and paint shops for sensor and actuator connections.

Outdoor LED Applications: Provides a waterproof connection for sensor systems integrated into outdoor LED street lights and large-scale display screens.

Renewable Energy: Connects sensors within wind turbine control systems and solar tracking units, exposed to harsh weather conditions.

Material Handling: Critical for AGVs (Automated Guided Vehicles) and conveyor system sensors in logistics and warehouse automation.

Frequently Asked Questions (FAQ)

Q1: What is the difference between A-coded and other M12 codings?
A1: M12 A-coded connectors are standardized for 3-wire DC sensors and actuators. Other codings, like B-coded for Fieldbus networks or D-coded for Ethernet, have different pin arrangements and key positions to prevent incorrect connections. Always verify the required coding for your device.

Q2: Is the IP67 rating sufficient for permanent submersion?
A2: No. The IP67 rating certifies protection against temporary immersion (up to 30 minutes at 1-meter depth). For permanent submersion, you would require a connector with an IP68 or IP69K rating.

Q3: What is the maximum voltage and current rating for this connector?
A3: Our standard M12 5-pin A-coded connector is rated for 250V AC/DC and a maximum current of 4A per pin. Please consult our datasheet for specific technical details.

Q4: Can I purchase cable assemblies, or just the separate plugs?
A4: We offer both pre-assembled, molded cable assemblies for immediate use and separate plug components for on-site field termination, providing flexibility for your installation needs.

Q5: What cable gauges are compatible?
A5: This connector is typically compatible with cable outer diameters between 4mm to 6.5mm, and supports conductor cross-sections from 0.14 mm² to 0.5 mm² (AWG 26 to AWG 20).
