Product Description

Shenzhen Jiayunkang Technology Co., Ltd. presents a robust and highly reliable high-voltage 2-pin male and female connector pair, engineered for demanding industrial and commercial applications. This connector set is specifically designed to provide a safe, stable, and completely waterproof connection for electrical systems operating under high voltage conditions. Crafted from premium, durable materials, it ensures excellent performance in harsh environments, including exposure to moisture, dust, vibration, and extreme temperatures. The intuitive plug-and-socket design allows for quick and secure mating, significantly reducing installation time and minimizing the risk of connection errors. This product is an ideal solution for transferring high-voltage power in outdoor, industrial, and specialized equipment where safety and reliability are paramount.

Product Features

High-Voltage Rating: Specifically engineered to handle high-voltage applications safely and efficiently, ensuring consistent power delivery.

2-Pin Configuration: A simple and effective two-contact design for power transmission (common and ground/live and neutral), suitable for a wide range of standard high-voltage setups.

Superior Waterproof Performance: Features an IP67 or higher rating, meaning it is dust-tight and can withstand immersion in water up to 1 meter for 30 minutes. This makes it perfect for outdoor and wet-location use.

Robust Construction: The connector housings are made from high-quality, engineering-grade thermoplastics that offer high impact resistance, excellent UV stability, and corrosion resistance.

Secure Locking Mechanism: Equipped with a threaded coupling or a robust snap-lock system that ensures a vibration-proof connection, preventing accidental disconnection.

High-Temperature Tolerance: The materials used can withstand a wide operating temperature range (e.g., -40°C to +105°C), ensuring performance stability in both extreme cold and heat.

Copper Alloy Contacts: The male pin and female socket contacts are crafted from high-conductivity copper alloy with precision plating (e.g., tin or gold), ensuring low resistance, high current-carrying capacity, and resistance to oxidation and arcing.

Flexible Cable Compatibility: Designed to be used with a range of standard cable diameters, providing flexibility for different installation requirements.

Product Advantages

Enhanced Safety and Reliability: The comprehensive sealing and robust insulation significantly reduce the risks of short circuits, electric shocks, and power failures, protecting both equipment and personnel.

Long Service Life and Durability: The use of premium materials and precision manufacturing results in a product that withstands mechanical stress, environmental challenges, and frequent mating/unmating cycles, offering a long lifespan and reducing long-term replacement costs.

Simplified Installation and Maintenance: The user-friendly design allows for quick and tool-free or minimal-tool mating. This streamlines the installation process, lowers labor costs, and facilitates easier system maintenance and component replacement.

Exceptional Environmental Sealing: Beyond just waterproofing, the integrated seals effectively keep out dirt, dust, and other contaminants, maintaining signal integrity and preventing corrosion in challenging settings like construction sites, marine applications, and agricultural machinery.

Optimized Electrical Performance: The high-quality contacts and optimal design minimize voltage drop and power loss, ensuring efficient energy transfer and stable operation of connected devices.

Global Market Compliance: Our connectors are designed to meet international safety and performance standards, making them a trustworthy choice for global supply chains and export-oriented projects.

Product Application Fields

This high-voltage 2-pin connector is versatile and finds critical use in numerous industries:

Outdoor LED Lighting Systems: Ideal for connecting high-power LED street lights, stadium lights, architectural facade lighting, and garden lights, where exposure to rain and weather is constant.

Industrial Automation and Machinery: Used on factory floors for connecting high-voltage sensors, motors, control cabinets, and heavy machinery that require reliable, vibration-resistant power connections.

New Energy Sector: Applicable in solar power generation systems for connecting photovoltaic panels and in charging infrastructure for electric vehicles (EV charging stations).

Marine and Automotive Electronics: Suitable for marine vessel electronics and in automotive applications requiring robust, waterproof power connections for auxiliary equipment.

Medical Equipment: Used in non-critical high-power medical devices where a secure and clean connection is necessary.

Telecommunications and Power Supply Systems: Deployed in base stations and power distribution units that operate outdoors or in controlled environments.

Product FQA

Q1: What is the IP rating of this connector, and what does it mean?
A1: This high-voltage 2-pin connector typically has an IP67 rating. This signifies it is completely protected against dust (6) and can be immersed in water between 15 cm and 1 meter deep for up to 30 minutes (7), ensuring reliable operation in rainy or humid conditions.

Q2: What is the maximum voltage and current this 2-pin connector can handle?
A2: While specific ratings can vary by model, our standard high-voltage 2-pin connectors are generally rated for voltages up to 600V or higher and currents up to 15-20A. Please refer to the specific product datasheet or contact our sales team for the exact specifications of the model you require.

Q3: Is the locking mechanism secure against vibrations?
A3: Absolutely. The connector features a threaded coupling or a high-retention snap-lock mechanism. This design ensures a firm connection that is highly resistant to loosening under vibration, which is common in industrial and automotive environments.

Q4: What cable types are compatible with this connector?
A4: This connector is designed to be compatible with a range of standard round cables. It typically includes a collet-type cable gland or compression seal that can accommodate various outer diameters, providing a secure and strain-relieved connection.

Q5: Are these connectors reusable?
A5: Yes, the connector housings are designed for multiple mating and unmating cycles without significant wear and tear. The internal contacts are also designed for durability, allowing for repeated use over the product's lifetime.

Q6: Can I request a custom cable assembly with this connector?
A6: Yes, as a specialized manufacturer, we offer custom cable assembly services. We can pre-wire these connectors onto your specified cable type and length, ready for immediate installation, saving you time and ensuring optimal performance.
