Product Description

Shenzhen Jiayunkang Technology Co., Ltd. presents a robust connectivity solution designed for modern electrical enclosures: the 4P Panel with Integrated IP67 Connector. This product is engineered to provide a secure, sealed, and reliable interface for power and signal transmission directly through control panels, junction boxes, and equipment housings. The integrated 4-pin (4P) IP67-rated connector eliminates the need for multiple individual feed-throughs, streamlining the assembly process and guaranteeing a consistent, high level of environmental protection.

This panel-mount solution is specifically constructed for applications where exposure to dust, moisture, high-pressure washdowns, and volatile weather conditions is a constant concern. By combining a durable panel body with our proven IP67 connector technology, we offer a complete, ready-to-install unit that ensures the internal components of your machinery, outdoor lighting, or automation systems remain completely protected. It serves as the critical, sealed gateway for electrical connections in demanding industrial and commercial settings.

Product Features

Integrated IP67 Protection: The unit is engineered as a single, sealed assembly, guaranteeing an Ingress Protection rating of IP67, ensuring it is dust-tight and can withstand temporary immersion in water.

4-Pole Configuration: Provides four distinct contact chambers, allowing for the simultaneous transmission of power, signals, or a combination of both in a single, compact interface.

Rugged Panel Construction: The panel body is manufactured from high-strength, corrosion-resistant materials such as engineered plastic or stainless steel, capable of withstanding physical impact and harsh chemical exposure.

Secure Locking Mechanism: Features a robust screw-lock or push-lock coupling system that prevents accidental disconnection, even in high-vibration environments.

Simplified Panel Mounting: Designed for easy installation from the outside of the enclosure, with a nut or clip retention system for a tight and secure fit.

Versatile Contact Compatibility: Accommodates a range of pin and socket contacts, suitable for various wire gauges and current ratings.

Product Advantages

Guaranteed System Integrity: The pre-assembled, factory-sealed design ensures a perfect IP67 seal every time, removing the risk of leaks associated with field-assembled gland and connector combinations. This directly protects sensitive internal electronics from failure.

Reduced Installation Time and Cost: By integrating the connector into the panel, we eliminate multiple components and assembly steps. This significantly cuts down on installation labor and reduces the total number of parts you need to source and manage.

Enhanced Durability and Longevity: The robust construction resists environmental stress, UV exposure (for outdoor models), and mechanical impact, leading to a longer service life and reduced maintenance requirements for the entire enclosure.

Streamlined and Professional Aesthetics: Provides a clean, unified, and professional appearance to equipment panels, superior to the look of multiple, separate cable glands and conduits.

Improved Safety: The sealed connection prevents the ingress of contaminants that could cause short circuits, electrical leaks, or corrosion, thereby enhancing overall operational safety.

Application Fields

This 4P Panel with IP67 Connector is ideal for any application requiring a protected pass-through for electrical connections.

Industrial Control Panels: For PLCs, motor drives, and automation controllers in manufacturing, packaging, and processing plants.

Outdoor LED Lighting Systems: As a sealed connection hub for LED street lights, floodlights, and architectural lighting fixtures.

Agricultural and Construction Machinery: On the control panels of tractors, harvesters, and excavators exposed to dust, mud, and water.

Renewable Energy Systems: Inverter and control unit enclosures for solar and wind power installations.

Marine and Offshore Equipment: Control boxes on boats, docks, and offshore platforms where saltwater corrosion is a concern.

Water and Wastewater Treatment: Equipment panels that require regular washdown and are exposed to humid, corrosive environments.

Frequently Asked Questions (FAQ)

Q1: What does the "4P" designation mean?
A: "4P" stands for "4-Pole." This means the connector has four separate electrical contact points, allowing you to run four independent circuits—such as power, ground, and signal lines—through a single, compact unit.

Q2: Can this panel-mounted connector be used in outdoor applications indefinitely?
A: Yes. The IP67 rating confirms it is completely protected against dust and can withstand temporary immersion, making it perfectly suitable for permanent outdoor use in harsh weather conditions.

Q3: Is the connector side of the panel also protected?
A: The IP67 rating applies to the entire assembled unit when the mating connector is plugged in and locked. This ensures the connection point itself is fully sealed against the environment.

Q4: What tools are needed for wiring the connector?
A: Standard crimping tools for the respective pin/socket contacts are required. The panel itself typically installs with a standard wrench or socket set.
