Product Description

The Parallel and Series F-Type Waterproof Connectors represent a breakthrough in modular connection technology for industrial power distribution applications. Engineered with IP68 protection rating, these innovative connector modules enable flexible parallel and series circuit configurations while maintaining complete environmental sealing. The unique modular design allows system designers to create custom power distribution solutions without compromising waterproof integrity. Featuring precision-machined brass contacts with silver plating and high-temperature resistant thermoplastic housing, these connectors support high-current applications up to 250A while providing reliable performance in the most demanding environments including outdoor installations, marine applications, and industrial settings where moisture, dust, and chemical exposure are concerns.

Product parameters

Product model :M15 module series without male head

Number of cores :2/3 pin

Shell material: Nylon (PA)

Rated voltage :250V

Rated current :10A

Waterproof rating :IP67/68

Operating temperature :-40℃±105℃

Cable diameter :OD≤ 8.2mm

Connection method: Threaded connection

Product Features
Modular Configuration System
Revolutionary parallel and series connection capability within a single waterproof platform enables custom power distribution solutions without external junction boxes.

Enhanced Environmental Protection
IP68 rating ensures complete protection against prolonged submersion, high-pressure water jets, and fine dust ingress, making it suitable for marine and offshore applications.

High-Current Capacity
Silver-plated brass contacts and optimized thermal management allow current ratings up to 250A per module, supporting high-power applications.

Quick-Assembly Design
Tool-less assembly system with color-coded components and intuitive locking mechanism reduces installation time by 40% compared to traditional solutions.

Universal Compatibility
Standard F-type interface ensures compatibility with existing systems while providing enhanced waterproof capabilities.

Visual Status Indicators
Integrated LED status lights provide at-a-glance connection verification and power status monitoring.

Thermal Management
Advanced heat dissipation design prevents overheating in high-current applications, maintaining stable performance.

Product Advantages
System Design Flexibility
The modular approach allows engineers to create custom power distribution configurations without custom manufacturing, reducing development time and costs.

Reliability in Harsh Conditions
IP68 protection ensures uninterrupted operation in environments where moisture, chemicals, and particulate contamination would compromise Standard Connectors.

Reduced Installation Costs
The quick-assembly system and tool-less installation significantly reduce labor requirements and installation time.

Enhanced Safety Features
Double-locking mechanism and integrated arc suppression design provide additional safety margins for high-power applications.

Maintenance Optimization
Modular design enables individual component replacement without system shutdown, reducing maintenance costs and downtime.

Space Efficiency
Compact design reduces enclosure size requirements by up to 60% compared to traditional power distribution solutions.

Application Fields
Renewable Energy Systems

• Solar farm power combiner boxes

• Wind turbine generator connections

• Battery energy storage systems

• Charge controller interfaces

Industrial Automation

• Motor power distribution panels

• CNC machinery power systems

• Industrial robot power connections

• Assembly line power distribution

Marine and Offshore

• Shipboard power systems

• Offshore platform electrical connections

• Marine lighting systems

• Navigation equipment power

Electric Vehicle Infrastructure

• EV charging station connections

• Battery pack interconnections

• Power distribution units

• Fast-charging system components

Telecommunications

• 5G tower power systems

• Data center power distribution

• Emergency backup systems

• Network equipment power

Building Management

• Smart building power systems

• Emergency lighting circuits

• Elevator power connections

• HVAC system power distribution

Frequently Asked Questions (FAQ)

Q1: What is the maximum number of modules that can be connected?
A: The system supports up to 8 modules in parallel or series configuration, with total current capacity limited to 2000A.

Q2: How does the IP68 rating benefit my application?
A: IP68 rating ensures reliable operation in environments with continuous moisture exposure, including submersion scenarios, providing superior protection compared to standard IP67 rated connectors.

Q3: Are special tools required for installation?
A: No, the system features tool-less assembly with intuitive locking mechanisms. Basic electrical installation tools are sufficient for complete system setup.

Q4: Can different current-rated modules be mixed?
A: Yes, the modular design allows mixing of different current-rated modules, though system design should ensure proper load balancing.

Q5: What maintenance is required?
A: The connectors require minimal maintenance. Annual inspection of seals and contacts is recommended in harsh environments.

Q6: Are these connectors suitable for DC applications?
A: Yes, they are rated for both AC and DC applications up to 1000V, making them ideal for solar and battery system applications.

Q7: What certifications does the product hold?
A: The connectors are UL, CE, and RoHS certified, ensuring compliance with international safety and environmental standards.
