Product Description

The M8 Male 4-Pin Circular Connector is a compact, high-performance interconnection solution engineered for demanding industrial environments. As part of the standardized M8 Connector family with A-coding, this 4-pin variant is primarily designed for high-speed data communication and signal transmission in sensors, actuators, and small-scale devices. It features a durable metal or high-grade plastic body with a secure screw-locking mechanism, ensuring a stable and reliable connection that resists vibration and accidental disconnection. This connector is an industry staple for connecting devices that use 4-wire configurations, such as Ethernet/IP networks, sensors, and various factory automation equipment, providing a perfect blend of miniaturization and robust performance. It is an essential component for creating streamlined, efficient, and protected electrical systems on the factory floor and in other challenging settings.

Product Features

Standardized A-Coding: Ensures perfect mating with 4-pin A-coded female sockets, preventing incorrect connections and safeguarding your equipment.

Rugged Construction: Available in robust metal or engineering-grade plastic housings to withstand physical impact, stress, and harsh conditions.

Secure Screw-Locking Mechanism: The threaded coupling system guarantees a vibration-proof connection, maintaining signal integrity even in high-vibration environments.

High-Performance Contacts: Precision-machined gold-plated pins ensure excellent conductivity, low resistance, and corrosion resistance for long-term reliability.

IP67 Rated Waterproof & Dustproof: Completely protected against dust ingress and the effects of temporary immersion in water (up to 1 meter for 30 minutes), making it ideal for wash-down areas and outdoor use.

Wide Temperature Range: Engineered to perform consistently across a broad operating temperature range, suitable for both cold storage and high-temperature industrial applications.

Flexible Cable Options: Compatible with various cable types, including PUR (polyurethane) for excellent oil and abrasion resistance, or PVC for general purpose use.

Product Advantages

Integrating our M8 Male 4-Pin Connector into your systems delivers significant, tangible benefits that enhance overall operational efficiency and reduce downtime.

Maximized System Uptime: The exceptional durability and reliable IP67 sealing minimize failures caused by environmental factors, leading to more stable production lines and lower maintenance costs.

Superior Signal Integrity: The optimized design and quality contacts minimize signal loss and electromagnetic interference (EMI), ensuring accurate data transmission for critical control and feedback signals.

Simplified Installation and Maintenance: The straightforward screw-locking design allows for quick and tool-free mating/unmating, speeding up initial setup and any subsequent servicing or reconfiguration.

Future-Proof Compatibility: Adherence to international M8 A-coded standards guarantees interoperability with a vast ecosystem of industrial devices from major manufacturers worldwide.

Space-Efficient Design: Its compact form factor is ideal for modern, high-density control cabinets and miniaturized equipment where space is at a premium, without compromising on performance.

Cost-Effective Solution: By offering a long service life and reducing the need for frequent replacements, this connector provides an excellent return on investment, lowering the total cost of ownership.

Product Application Fields

The versatility and robustness of the M8 Male 4-Pin Connector make it indispensable across a wide spectrum of industries and applications.

Industrial Automation & Robotics: Connecting sensors, limit switches, photoelectric sensors, encoders, and small actuators on robotic arms and automated guided vehicles (AGVs).

Process Control Systems: Wiring for pressure transmitters, temperature sensors, and flow meters in chemical, food & beverage, and pharmaceutical processing plants.

EtherNET/IP & Profinet Networks: Serving as a compact interface for Device-Level Ring (DLR) networks and fieldbus systems in structured industrial networking.

Automotive Manufacturing: Used extensively in assembly line machinery, welding robots, and control sensors within automotive production facilities.

Packaging Machinery: Providing reliable connections for barcode readers, vision systems, and control elements on high-speed packaging and labeling machines.

Outdoor & Harsh Environments: Suitable for outdoor LED lighting control, telecommunications infrastructure, and agricultural equipment exposed to dust and moisture.

Product Frequently Asked Questions (FAQ)

Q1: What is the difference between A-code and B-code M8 connectors?
A1: A-coded M8 connectors are standardized for 3-pin or 4-pin configurations used in sensors, data, and power. B-coded M8 connectors are specifically for 4-pin PROFIBUS networks and feature a different keying position to prevent mating with A-coded sockets. Our 4-Pin A-Coded Connector is not compatible with B-coded systems.

Q2: Can this connector be used for power transmission?
A2: While it can carry power, the M8 4-pin A-coded connector is primarily optimized for data and signal transmission, such as in Ethernet/IP applications. For dedicated power applications, it is crucial to check the voltage and current ratings against your requirements to avoid overheating.

Q3: What is the significance of the IP67 rating?
A3: The IP67 rating means the connector is "Ingress Protection" level 6 (completely dust-tight) and level 7 (protected against immersion in water between 15cm and 1 meter for up to 30 minutes). This makes it suitable for environments with high dust, humidity, or occasional water exposure, like factory wash-down areas.

Q4: What types of cable are best suited for this connector?
A4: We recommend using PUR (Polyurethane) jacketed cables for the best performance in harsh conditions. PUR offers superior resistance to oil, chemicals, abrasion, and hydrolysis. PVC cables are a cost-effective alternative for less demanding, general-purpose indoor applications.

Q5: Is this a plug or a socket?
A5: This specific product is a Male connector, meaning it has the pins. It is designed to mate with a Female M8 connector, which has the sockets.
