Product Description

Shenzhen Jiayunkang Technology Co., Ltd. presents the M123 Series, a premium line of pin-type Push-Pull Connectors engineered for applications where reliability, speed, and environmental sealing are critical. This connector embodies a sophisticated quick-locking mechanism that allows for intuitive engagement and disengagement with a simple push and pull motion, eliminating the need for bulky threaded couplings or tools. Designed to meet the rigorous demands of modern industry, the M123 connector ensures a secure, vibration-proof connection for power, signal, and data transmission.

The compact yet robust design of the M123 makes it an ideal solution for space-constrained panels in medical devices, industrial automation, and professional audio/video equipment. It features precision-machined pin contacts and high-performance engineering thermoplastics, providing excellent mechanical strength and chemical resistance. This connector series is a testament to our commitment to manufacturing advanced interconnection solutions that enhance operational efficiency and device reliability on a global scale.

Product Features

Quick Push-Pull Locking: Enables fast and secure mating and unmating in seconds, significantly reducing connection time and improving workflow efficiency.

High-Cycle Durability: Engineered for thousands of mating cycles without performance degradation, ensuring long-term reliability and reducing replacement costs.

Superior Environmental Sealing: Rated at IP65/IP67, offering robust protection against dust, water ingress, and high-pressure jet sprays, making it suitable for harsh environments.

Anti-Snag and Splash-Proof Design: The smooth, ergonomic housing prevents snagging and features a sealed interface that protects contacts from moisture and contaminants before mating.

Precision Pin Contacts: Gold-plated pin terminals ensure low contact resistance, stable signal integrity, and high corrosion resistance for optimal electrical performance.

Audible and Tactical Click: A distinct click upon full mating provides clear confirmation of a secure connection, preventing incomplete engagements.

Color Coding Options: Available in multiple standard housing colors for easy circuit identification and inventory management.

Product Advantages

Maximized Operational Efficiency: The rapid push-pull mechanism drastically reduces connection time, leading to faster device setup, maintenance, and deployment in fields like mobile medical equipment and live event production.

Uncompromised Connection Security: The locking mechanism is designed to resist shock and vibration, preventing accidental disconnections that can lead to system failure or data loss in critical applications.

Enhanced User Safety and Ergonomics: The intuitive operation requires minimal force and can be used with one hand, even while wearing gloves, improving user experience and safety in complex operational scenarios.

Reduced Total Cost of Ownership: The combination of high durability, excellent sealing, and reliable performance minimizes downtime, maintenance needs, and the frequency of connector replacements.

Design Flexibility for Engineers: Available in various pin configurations and solder or crimp termination styles, the M123 series offers engineers the flexibility to integrate a reliable connection standard into diverse product designs.

Application Fields

The M123 Pin Push-Pull Connector is versatile and trusted across a wide range of high-tech industries:

Medical and Dental Equipment: Ideal for patient monitoring devices, portable diagnostic equipment, surgical handpieces, and imaging systems where speed and reliability are paramount.

Industrial Automation & Robotics: Used for connecting sensors, controllers, and actuators on automated machinery and robotic arms that require frequent disconnection for reconfiguration or maintenance.

Professional Audio-Visual & Broadcast: The perfect choice for microphones, intercom systems, lighting control, and video cameras in studio and live event environments.

Test & Measurement Instruments: Provides reliable interconnections for data acquisition systems, portable scanners, and field test equipment exposed to demanding conditions.

Communications and IT Peripherals: Used in network hardware and specialized computing devices where secure, quick-connect interfaces are needed.

Frequently Asked Questions (FAQ)

Q1: What is the main difference between a push-pull connector and a Threaded Connector?
A: Push-pull connectors offer a much faster and more user-friendly connection, mating and unmating in seconds without the need to rotate the coupling nut. Threaded connectors, while very secure, require more time and effort to screw in and out.

Q2: Can the M123 connector withstand autoclave or chemical sterilization processes?
A: Standard M123 models are chemically resistant but not typically rated for repeated autoclaving. We offer specialized versions with high-temperature resistant materials for sterilization applications. Please contact our sales team for specific requirements.

Q3: What is the mating cycle life of the M123 series?
A: The M123 connector is engineered for a high mating cycle life, typically exceeding 5,000 cycles while maintaining its electrical and mechanical integrity, including its IP rating.

Q4: Are custom cable assemblies available for the M123 connector?
A: Yes. As a manufacturer, we specialize in providing custom-length cable assemblies terminated with M123 connectors, tailored to your specific application needs, including different jacket materials and shielding options.
