Product Description

Shenzhen Jiayunkang Technology Co., Ltd. presents a high-performance M12 1.25mm Pitch, 2-Pin Panel Mount Connector, engineered for precision and durability in compact automation and sensor applications. This connector features a threaded panel mounting design, allowing for secure and stable installation directly onto machine frames, control cabinets, or equipment enclosures. The 2-pin configuration in the space-efficient M12 form factor, with a fine 1.25mm pin pitch, is ideally suited for DC power and signal transmission to a wide array of industrial devices.

Crafted from robust PBT housing and featuring gold-plated contacts for superior conductivity and corrosion resistance, this connector is built to endure the rigors of industrial environments. It serves as a reliable fixed port, enabling quick and secure connections for sensors, actuators, and other peripheral devices in automated systems, thereby streamlining wiring and reducing installation time.

Product Features

Standardized M12 Interface: Features the universally recognized M12 x 1.0 threaded coupling nut for a secure, vibration-resistant connection, ensuring compatibility with a vast ecosystem of industrial devices.

Fine 1.25mm Pin Pitch: The compact pin spacing allows for a small form factor while maintaining reliable performance for low-current applications, making it ideal for miniaturized equipment.

Secure Panel Mounting: Designed with a threaded nut and sealing ring for easy and firm installation into panel cutouts, providing a stable and rattle-free interface.

High-Grade Materials: The connector body is made from chemical-resistant and high-temperature PBT plastic, ensuring long-term performance even in harsh conditions.

Optimized Contact Design: Precision-machined, gold-plated pin contacts offer low insertion force, excellent electrical characteristics, and high resistance to oxidation and fretting corrosion.

Efficient Wiring: Supports fast and reliable screw termination or crimping for simplified field wiring, reducing assembly time and labor costs.

Product Advantages

Enhanced System Reliability: The robust panel mount design creates a fixed and sturdy connection point, drastically reducing failures caused by loose cables or port damage, which maximizes machine uptime.

Superior Space Utilization: The compact M12 design with a 1.25mm pitch is perfect for high-density applications where control panel space is at a premium, allowing for more connections in a smaller area.

Exceptional Environmental Sealing: When properly installed with its integrated seal, the connector typically achieves an IP67 rating, providing complete protection against dust ingress and temporary immersion in water, suitable for wash-down environments and outdoor use.

Streamlined Maintenance and Replacement: The standardized M12 interface allows for quick device replacement or system reconfiguration without the need for specialized tools, minimizing maintenance downtime.

Long-Term Cost Savings: The combination of durable materials, reliable performance, and easy installation translates into a lower total cost of ownership by reducing maintenance needs and connection-related failures.

Application Fields

This M12 2-pin panel mount connector is a fundamental component across numerous industries requiring dependable, compact interconnects.

Factory Automation & Robotics: Connecting proximity sensors, photoelectric sensors, small actuators, and IO-Link devices on control panels and machinery.

Industrial Sensor Networks: Serving as a fixed interface for pressure, temperature, and flow sensors in process control and monitoring systems.

Packaging and Material Handling Equipment: Providing power and signal connections for sensors in conveyor systems and automated packaging machines.

LED Lighting Systems: Used in control systems for industrial and outdoor LED lighting fixtures, especially where a compact, sealed connection is required.

Telecommunications and Network Infrastructure: Interfacing with specific network and communication equipment that utilizes M12 connections for robustness.

Frequently Asked Questions (FAQ)

Q1: What is the typical current rating for this 2-pin M12 Connector?
A: This 2-pin, 1.25mm pitch connector is generally rated for up to 1.5 Amps per pin, making it suitable for low-power sensor and signal applications. Always confirm with the specific product datasheet for your voltage and current requirements.

Q2: What is the mating cycle durability of this connector?
A: Our M12 connectors are designed for high durability, typically rated for 100 or more mating cycles, ensuring long-term reliability even in applications requiring frequent connection and disconnection.

Q3: What is the recommended panel cutout size for installation?
A: The standard panel cutout diameter for this M12 panel mount connector is 12.5mm. Please refer to the technical drawing in our datasheet for precise dimensions and installation guidelines.

Q4: Is this connector compatible with IO-Link applications?
A: While this 2-pin version is primarily for power and standard signal, the M12 form factor is standard for IO-Link. For IO-Link communication, a specific pinout (often 3 or 4-pin) is required. Please ensure the pin configuration matches your device's protocol.
